pyeDSL – Embedded Domain Specific Language in python

The Signal class serves it purpose to get a raw data for a single signal. However, it makes it difficult to generalize in order to acquire the same signal across several circuits. In addition, typical processing requires to use additional classes and introduce even more local variables


circuit_type = 'RB'
circuit_name = 'RB.A12'
t_start = '2015-01-13 16:59:11+01:00'
t_end = '2015-01-13 17:15:46+01:00'
db = 'NXCALS'
system = 'PC'

metadata_pc = SignalMetadata.get_circuit_signal_database_metadata(circuit_type, circuit_name, system, db)
I_MEAS = SignalMetadata.get_signal_name(circuit_type, circuit_name, system, db, 'I_MEAS')

i_meas_nxcals_df = Signal().read(db, signal=I_MEAS, t_start=t_start, t_end=t_end,
                                 nxcals_device=metadata_pc['device'], nxcals_property=metadata_pc['property'], nxcals_system=metadata_pc['system'],
                                 spark=spark)

i_meas_nxcals_df = SignalUtilities.synchronize_df(i_meas_nxcals_df)
i_meas_nxcals_df = SignalUtilities.convert_indices_to_sec(i_meas_nxcals_df)

Several design flaws leading to inconsistency and code duplications:

  • use of multiple methods, multiple arguments (duplicated across methods)
  • multiple local variables (naming consistency across analysis modules)
  • order of methods and arguments (with duck typing) not fixed

The API also does not answer in a generic way the following questions

  • What if we want to get current for each circuit?
  • What if we want to get several current signals?

Natural languages have certain structure [1]

LanguageWord orderExample
English:{Subject}.{Verb}.{Object}:John ate cake
Japanese:{Subject}.{Order}.{Verb}:John-ga keiki-o tabeta
––John cake ate

One can enforce syntactical order in code:

  • Domain Specific Language – new language, requires parser
  • Embedded Domain Specific Language – extends existing language

Furthermore, an eDSL could be implemented following the Fluent interface approach [2]. The use of an eDSL for signal query and processing is not a new concept as there exists already an eDSL in Java used to automatically check signals during Hardware Commisionning campaigns of the LHC [3].

[1] K. Gulordava, Word order variation and dependency length minimisation: a cross-linguistic computational approach, PhD thesis, UniGe,
[2] https://en.wikipedia.org/wiki/Fluent_interface
[3] M. Audrain, et al. – Using a Java Embedded Domain-Specific Language for LHC Test Analysis, ICALEPCS2013, San Francisco, CA, USA

1. QueryBuilder()

We propose a python embedded Domain Specific Language (pyeDSL) for building queries:

  • General purpose query
    {DB}.{DURATION}.{QUERY_PARAMETERS}.{QUERY}

e.g.


df = QueryBuilder().{with_pm()/with_cals()/with_nxcals()}.with_duration().with_query_parameters()\
    .signal_query().dfs[0]
df = QueryBuilder().{with_pm()/with_cals()/with_nxcals()}.with_timestamp().with_query_parameters()\
    .signal_query().dfs[0]
  • Circuit-oriented query to generalize query across and within circuit types
    {DB}.{DURATION}.{CIRCUIT_TYPE}.{METADATA}.{QUERY}

e.g.


df = QueryBuilder().{with_pm()/with_cals()/with_nxcals()}.with_duration().with_circuit_type().with_metadata()\
    .signal_query().dfs[0]
df = QueryBuilder().{with_pm()/with_cals()/with_nxcals()}.with_timestamp().with_circuit_type().with_metadata()\
    .signal_query().dfs[0]
  • each parameter defined once (validation of input at each stage)
  • single local variable
  • order of operation is fixed
  • support for vector inputs
  • time-dependent metadata

The pyeDSL provides hints on the order of execution

In [61]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

QueryBuilder()

Out[61]:


Set database name using with_pm(), with_cals(ldb), with_nxcals(spark) method.

In [62]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

QueryBuilder().with_nxcals(spark)

Out[62]:


Database name properly set to NXCALS. Set time definition: for PM signal query, with_timestamp(),
 for PM event query or CALS, NXCALS signal query, with_duration()

In [63]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

QueryBuilder().with_nxcals(spark).with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')])

Out[63]:


Query duration set to t_start=1426220359491000200, t_end=1426220559491000200. Set generic query parameter using with_query_parameters() method, or a circuit signal using with_circuit_type() method.

At the same time it prohibits unsupported operations throwing a meaningful exception

In [64]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

QueryBuilder().with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')])


---------------------------------------------------------------------------
AttributeError                            Traceback (most recent call last)
<ipython-input-64-17466de21b88> in <module>()
      1 from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
      2
----> 3 QueryBuilder().with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')])

/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/QueryBuilder.py in __getattr__(self, name)
    134     def __getattr__(self, name):
    135         if name not in ['query', 'with_pm', 'with_cals', 'with_nxcals']:
--> 136             raise AttributeError('{}() is not supported. {}'.format(name, self._msg))
    137
    138     def __repr__(self):

AttributeError: with_duration() is not supported. Set database name using with_pm(), with_cals(ldb), with_nxcals(spark) method.

Sections 1.1 – 1.6. deal with: PM event and signal query, CALS signal query, NXCALS signal and feature query (as shown in Table 1). Each case is discussed with a general purpose query, where the user has to provide full data on signal name and its metadata as well as circuit-oriented queries which provide a generic way of querying LHC circuit variables. Both query types are polymorphic and complemented with a set of post-processing functions.

*Since CALS is about to be discontinued at CERN, we do not support this type of query. For feature query with pytimber, please consult https://gitlab.cern.ch/scripting-tools/pytimber

1.1. General-Purpose Query – Examples

A sentence constructed this way maintains the differences of query types while providing a common structure

  • PM event query

In [65]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_query_parameters(system='FGC', className='51_self_pmd', source='RPTE.UA47.RB.A45') \
    .event_query().df

source_timestamp_df

Out[65]:

sourcetimestamp
0RPTE.UA47.RB.A451426220469520000000

In [66]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_query_parameters(system='QPS', className='DQAMCNMB_PMHSU', source='*') \
    .event_query().df

source_timestamp_df

Out[66]:

sourcetimestamp
0B20L51426220469491000000
1C20L51426220517100000000
2A20L51426220518112000000
3A21L51426220625990000000
4B21L51426220866112000000
5C23L41426236802332000000
6B23L41426236839404000000
7A23L41426236839832000000
8C22L41426236949841000000
9C15R41426251285711000000
10B15R41426251337747000000
11A15R41426251388741000000
12B34L81426258716281000000
13C34L81426258747672000000
14A34L81426258747370000000
15C33L81426258835955000000
16C34R71426258853947000000
17A34R71426258854113000000
18A20R31426267931956000000
19B20R31426267983579000000
20C20R31426268004144000000
21B18L51426277626360000000
22A18L51426277679838000000
23C18L51426277680496000000
24A19L51426277903449000000
  • PM signal query

In [67]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_pm() \
    .with_timestamp(1426220469520000000) \
    .with_query_parameters(system='FGC', source='RPTE.UA47.RB.A45', className='51_self_pmd', signal='STATUS.I_MEAS') \
    .signal_query().dfs[0]

i_meas_df.plot()

Out[67]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f847dd1d978>
  • CALS signal query

In [68]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
import pytimber
ldb = pytimber.LoggingDB()

i_meas_df = QueryBuilder().with_cals(ldb) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_query_parameters(signal='RPTE.UA47.RB.A45:I_MEAS') \
    .signal_query().dfs[0]

i_meas_df.plot()


WARNING:cmmnbuild_dep_manager:JVM is already started

Out[68]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f847dcbbeb8>
  • NXCALS signal query – device, property

In [69]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_query_parameters(nxcals_system='CMW', nxcals_device='RPTE.UA47.RB.A45', nxcals_property='SUB', signal='I_MEAS') \
    .signal_query().dfs[0]

i_meas_df.plot()

Out[69]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474c97400>
  • NXCALS signal query – variable

In [70]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_query_parameters(nxcals_system='WINCCOA', signal='DCBA.15R4.R:U_MAG') \
    .signal_query().dfs[0]

u_mag_df.plot()

Out[70]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f847c00a9b0>

In [71]:


bmode_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', t_end='2015-04-13 05:20:59.4910002') \
    .with_query_parameters(nxcals_system='CMW', signal='HX:BMODE') \
    .signal_query().dfs[0]

bmode_df.head()

Out[71]:

HX:BMODE
1426513864882000000SETUP
1426515551191000000NOBEAM
1426597426610000000SETUP
1426597576404000000STABLE
1426598591040000000UNSTABLE
  • NXCALS feature query – device, property

I_MEAS from beam injection, through beam acceleration, to stable beams

In [72]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1526898157236000000, t_end=1526903352338000000) \
    .with_query_parameters(nxcals_system='CMW', nxcals_device='RPTE.UA23.RB.A12', nxcals_property='SUB', signal='I_MEAS') \
    .feature_query(['mean', 'std', 'max', 'min', 'count']).df

i_meas_df

Out[72]:

devicemeanstdmincountmax
0RPTE.UA23.RB.A125374.7686593315.972856757.18249810978.8
  • NXCALS feature query – variable

U_MAG from beam injection, through beam acceleration, to stable beams

In [73]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1526898157236000000, t_end=1526903352338000000) \
    .with_query_parameters(nxcals_system='WINCCOA', signal='DCBB.8L2.R:U_MAG') \
    .feature_query(['mean', 'std', 'max', 'min', 'count']).df

u_mag_df

Out[73]:

nxcals_variable_namemeanstdmincountmax
0DCBB.8L2.R:U_MAG-0.1967060.375195-0.975332519510.002113

1.2. General-Purpose Query – Polymorphism

  • multiple signal, mutliple sources, multiple systems, multiple className

In [74]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_pm() \
    .with_timestamp(1426220469520000000) \
    .with_query_parameters(system=['FGC', 'FGC'], source=['RPTE.UA47.RB.A45', 'RPTE.UA47.RB.A45'],
                           className=['51_self_pmd', '51_self_pmd'], signal=['STATUS.I_MEAS', 'STATUS.I_REF']) \
    .signal_query().dfs

ax=i_meas_df[0].plot()
i_meas_df[1].plot(ax=ax)

Out[74]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474d73b00>
  • multiple signal, single source, single system, single className

In [75]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_pm() \
    .with_timestamp(1426220469520000000) \
    .with_query_parameters(system='FGC', source='RPTE.UA47.RB.A45',
                           className='51_self_pmd', signal=['STATUS.I_MEAS', 'STATUS.I_REF']) \
    .signal_query().dfs

ax=i_meas_df[0].plot()
i_meas_df[1].plot(ax=ax)

Out[75]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474d9a400>

1.3. Circuit-Oriented Query – Examples

  • PM event query

In [76]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='PC') \
    .event_query().df

source_timestamp_df

Out[76]:

sourcetimestamp
0RPTE.UA47.RB.A451426220469520000000

In [77]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QH', source='*') \
    .event_query().df

source_timestamp_df

Out[77]:

sourcetimestamp
0B20L51426220469491000000
1C20L51426220517100000000
2A20L51426220518112000000
3A21L51426220625990000000
4B21L51426220866112000000
5C23L41426236802332000000
6B23L41426236839404000000
7A23L41426236839832000000
8C22L41426236949841000000
9C15R41426251285711000000
10B15R41426251337747000000
11A15R41426251388741000000
12B34L81426258716281000000
13C34L81426258747672000000
14A34L81426258747370000000
15C33L81426258835955000000
16C34R71426258853947000000
17A34R71426258854113000000
18A20R31426267931956000000
19B20R31426267983579000000
20C20R31426268004144000000
21B18L51426277626360000000
22A18L51426277679838000000
23C18L51426277680496000000
24A19L51426277903449000000
  • PM signal query

In [78]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_pm() \
    .with_timestamp(1426220469520000000) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='PC', signal='I_MEAS') \
    .signal_query().dfs[0]

i_meas_df.plot()

Out[78]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474c56a58>
  • CALS signal query

In [79]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
import pytimber
ldb = pytimber.LoggingDB()

i_meas_df = QueryBuilder().with_cals(ldb) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='PC', signal='I_MEAS')\
    .signal_query().dfs[0]

i_meas_df.plot()


WARNING:cmmnbuild_dep_manager:JVM is already started

Out[79]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474b969e8>
  • NXCALS signal query – device, property

In [80]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='PC', signal='I_MEAS') \
    .signal_query().dfs[0]

i_meas_df.plot()

Out[80]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474b497f0>
  • NXCALS signal query – variable

In [81]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': 'DCBA.15R4.R'}) \
    .signal_query().dfs[0]

u_mag_df.plot()

Out[81]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474b19a90>
  • NXCALS feature query – device, property

I_MEAS from beam injection, through beam acceleration, to stable beams

In [82]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1526898157236000000, t_end=1526903352338000000) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='PC', signal='I_MEAS') \
    .feature_query(['mean', 'std', 'max', 'min', 'count']).df

i_meas_df

Out[82]:

devicemeanstdmincountmax
0RPTE.UA23.RB.A125374.7686593315.972856757.18249810978.8
  • NXCALS feature query – variable

U_MAG from beam injection, through beam acceleration, to stable beams

In [83]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1526898157236000000, t_end=1526903352338000000) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': 'DCBB.8L2.R'}) \
    .feature_query(['mean', 'std', 'max', 'min', 'count']).df

u_mag_df

Out[83]:

nxcals_variable_namemeanstdmincountmax
0DCBB.8L2.R:U_MAG-0.1967060.375195-0.975332519510.002113

1.4. Circuit-Oriented Query – Polymorphism

  • Multiple circuit names

In [84]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_dfs = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(100, 's'), (100, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name=['RB.A12', 'RB.A45'], system='PC', signal='I_MEAS')\
    .signal_query().dfs

ax = i_meas_dfs[0].plot()
i_meas_dfs[1].plot(ax=ax, grid=True)

Out[84]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474aa5ba8>
  • Multiple system names

In [85]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_hts_dfs = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1544622149598000000, duration=[(50, 's'), (150, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system=['LEADS_EVEN', 'LEADS_ODD'], signal='U_HTS') \
    .signal_query().dfs

ax = u_hts_dfs[0].plot()
u_hts_dfs[1].plot(ax=ax)

Out[85]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474aa3748>
  • Multiple signal names

In [86]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_ext_dfs = QueryBuilder().with_pm() \
    .with_timestamp(1544622149598000000) \
    .with_circuit_type('RQ') \
    .with_metadata(circuit_name='RQD.A12', system='QDS', signal=['U_1_EXT', 'U_2_EXT'],
                        source='16L2', wildcard={'CELL': '16L2'}) \
    .signal_query().dfs

ax = u_ext_dfs[0].plot()
u_ext_dfs[1].plot(ax=ax)

Out[86]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f8474be5ba8>
  • Signal wildcard

In [87]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
import matplotlib.pyplot as plt
import pytimber
ldb = pytimber.LoggingDB()

u_diode_rqd_dfs = QueryBuilder().with_cals(ldb) \
    .with_duration(t_start=int(1544622149613000000), duration=[(50, 's'), (150, 's')]) \
    .with_circuit_type('RQ') \
    .with_metadata(circuit_name='RQD.A12', system='DIODE_RQD', signal='U_DIODE_RQD', wildcard={'MAGNET': '*'})\
    .signal_query().dfs

# plot all
fig, ax = plt.subplots()
for u_diode_rqd_df in u_diode_rqd_dfs:
    u_diode_rqd_df.plot(ax=ax)
ax.legend().set_visible(False)


WARNING:cmmnbuild_dep_manager:JVM is already started

1.5. Advanced Feature Query

NXCALS enables calculation of signal features such as min, max, mean, std, count directly on the cluster without the need for costly query of the signal and performing calculation locally. This approach enables parallel computing on the cluster. To this end, a query should contain an element enabling a group by operation. Each group by operation allows for executing computation in parallel. For the sake of compactness, we only show examples for circuit-oriented query, however, the same principle applies to the general-purpose queries.

  • Feature query of multiple signals for the same period of time

In [88]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=1526898157236000000, t_end=1526903352338000000) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='*', system='PC', signal='I_MEAS') \
    .feature_query(['mean', 'std', 'max', 'min', 'count']).df

i_meas_df

Out[88]:

devicemeanstdmincountmax
0RPTE.UA63.RB.A565372.6363693314.646638756.90249810974.36
1RPTE.UA87.RB.A815371.5969903314.230379756.82249810973.21
2RPTE.UA83.RB.A785369.2269343312.676833756.47249810967.94
3RPTE.UA27.RB.A235373.9731513315.324716757.04249810976.46
4RPTE.UA43.RB.A345373.5591313314.074552756.95249710975.16
5RPTE.UA67.RB.A675374.3291793315.855302757.18249810978.56
6RPTE.UA47.RB.A455370.9545573312.837184756.71249710971.44
7RPTE.UA23.RB.A125374.7686593315.972856757.18249810978.80
  • Feature query of multiple signals with the same period of time subdivided into three intervals – group by signal name and interval

In [89]:


t_start_injs = 1526898157236000000
t_end_injs = 1526899957236000000
t_start_sbs = 1526901552338000000
t_end_sbs = 1526903352338000000

In [90]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='PC', signal='I_MEAS')\
    .signal_query().dfs[0]

ax = i_meas_df.plot(figsize=(10,5), linewidth=5)
ax.axvspan(xmin=t_start_injs, xmax=t_end_injs, facecolor='xkcd:goldenrod')
ax.axvspan(xmin=t_end_injs, xmax=t_start_sbs, facecolor='xkcd:grey')
ax.axvspan(xmin=t_start_sbs, xmax=t_end_sbs, facecolor='xkcd:green')

Out[90]:


<matplotlib.patches.Polygon at 0x7f846ff09e10>

Function translate introduces a mapping based on the time column. Here, we consider three subintervals for beam injection, beam acceleration, and stable beams.

As a result, the time column forms a partition and can be executed in parallel.

In [91]:


from pyspark.sql.functions import udf
from pyspark.sql.types import IntegerType

def translate(timestamp):
    if(timestamp >= t_start_injs and timestamp < t_end_injs):
        return 1

    if(timestamp >=  t_end_injs and timestamp < t_start_sbs):
        return 2

    if(timestamp >= t_start_sbs and timestamp <= t_end_sbs):
        return 3

    return -1

translate_udf = udf(translate, IntegerType())

The translate function should be passed as a function argument

In [92]:


i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='*', system='PC', signal='I_MEAS') \
    .feature_query(['mean', 'std', 'max', 'min', 'count'], function=translate_udf).df

i_meas_df

Out[92]:

deviceclassmeanstdmincountmax
0RPTE.UA43.RB.A341756.9598330.001291756.9560756.96
1RPTE.UA63.RB.A56310974.3501670.00129110974.356010974.36
2RPTE.UA47.RB.A45310971.4396670.00181010971.436010971.44
3RPTE.UA47.RB.A4525346.0599713193.562789756.71237710970.89
4RPTE.UA23.RB.A12310978.7815000.00755210978.776010978.80
5RPTE.UA83.RB.A7825344.3499413193.572017756.47237810967.54
6RPTE.UA43.RB.A3425348.6959493194.776339756.95237710974.68
7RPTE.UA67.RB.A671757.1888330.003237757.1860757.19
8RPTE.UA87.RB.A81310973.2091670.00278710973.206010973.21
9RPTE.UA27.RB.A2325349.1064343196.138736757.04237810976.10
10RPTE.UA83.RB.A78310967.9400000.00000010967.946010967.94
11RPTE.UA47.RB.A451756.7100000.000000756.7160756.71
12RPTE.UA83.RB.A781756.4720000.004034756.4760756.48
13RPTE.UA27.RB.A231757.0468330.004691757.0460757.05
14RPTE.UA87.RB.A8125346.6976373195.063002756.83237810972.79
15RPTE.UA87.RB.A811756.8291670.002787756.8260756.83
16RPTE.UA23.RB.A1225349.8793613196.753501757.19237810978.41
17RPTE.UA67.RB.A6725349.4238653196.631627757.18237810978.15
18RPTE.UA63.RB.A5625347.7587973195.477077756.90237810973.97
19RPTE.UA43.RB.A34310975.1548330.00503910975.156010975.16
20RPTE.UA23.RB.A121757.2016670.007847757.1860757.22
21RPTE.UA27.RB.A23310976.4503330.00181010976.456010976.46
22RPTE.UA63.RB.A561756.9036670.004860756.9060756.91
23RPTE.UA67.RB.A67310978.5501670.00129110978.556010978.56

The same method applied to NXCALS signals based on variable

In [93]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_ab_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': 'DCBB.8L2.R'}) \
    .feature_query(['mean', 'std', 'max', 'min', 'count'], function=translate_udf).df

u_mag_ab_df

Out[93]:

nxcals_variable_nameclassmeanstdmincountmax
0DCBB.8L2.R:U_MAG3-0.0019830.002882-0.034035180000.002003
1DCBB.8L2.R:U_MAG1-0.0018610.002844-0.005992180000.002113
2DCBB.8L2.R:U_MAG2-0.6363150.423767-0.975332159510.002041

This method can be used together with signal decimation, i.e., taking every nth sample.

For example this can be useful to query QPS board A and B which share the same channel and samples are shifted by 5 so that

  • every 10-th sample belongs to board A (or B), decimation=10

In [94]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_a_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': 'DCBB.8L2.R'}) \
    .feature_query(['mean', 'std', 'max', 'min', 'count'], function=translate_udf, decimation=10).df

u_mag_a_df

Out[94]:

nxcals_variable_nameclassmeanstdmincountmax
0DCBB.8L2.R:U_MAG30.0008120.000529-0.01270518000.002003
1DCBB.8L2.R:U_MAG10.0009650.000434-0.00046318000.002113
2DCBB.8L2.R:U_MAG2-0.6336010.423847-0.96940515950.002041
  • every 5+10-th sample belongs to board B (or A), decimation=10, shift=5

In [95]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_b_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': 'DCBB.8L2.R'}) \
    .feature_query(['mean', 'std', 'max', 'min', 'count'], function=translate_udf, decimation=10, shift=5).df

u_mag_b_df

Out[95]:

nxcals_variable_nameclassmeanstdmincountmax
0DCBB.8L2.R:U_MAG3-0.0047540.000877-0.0340351800-0.003425
1DCBB.8L2.R:U_MAG1-0.0046560.000441-0.0059921800-0.003361
2DCBB.8L2.R:U_MAG2-0.6392330.423941-0.9753321595-0.003052
  • with polymorphism one can query 1248 busbar at once (in two batches of 624 due to the limit of 1000 signal per query)

In [96]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

u_mag_ab_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start_injs, t_end=t_end_sbs) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='*', system='BUSBAR', signal='U_MAG', wildcard={'BUSBAR': '*'}) \
    .feature_query(['mean', 'std', 'max', 'min', 'count'], function=translate_udf).df

u_mag_ab_df.head()

Out[96]:

nxcals_variable_nameclassmeanstdmincountmax
0DCBA.B34R3.L:U_MAG20.6348130.4234180.000184159510.970042
1DCBA.22L4.L:U_MAG1-0.0011100.000639-0.00210218000-0.000167
2DCBB.11L2.R:U_MAG30.0014570.002587-0.002121180000.048651
3DCBA.B33L5.L:U_MAG20.6346510.423401-0.001109159510.971211
4DCBA.B13L5.L:U_MAG20.6324620.423240-0.002246159510.968428

1.6. Processing Raw Signals

Once a signal is queried, one can perform some operations on each of them.
In this case, the order of operations does not matter (but can be checked).

Signal querySignal processing
{DB}.{DURATION}.{QUERY_PARAMETERS}.{QUERY}
{DB}.{DURATION}.{CIRCUIT_TYPE}.{METADATA}.{QUERY}
.synchronize_time()
.convert_index_to_sec()
.create_col_from_index()
.filter_median()
.remove_values_for_time_less_than()
.remove_initial_offset()

In [97]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

i_meas_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2015-01-13 16:59:11+01:00', t_end='2015-01-13 17:15:46+01:00') \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='PC', signal='I_MEAS') \
    .signal_query() \
    .synchronize_time() \
    .convert_index_to_sec().dfs[0]

i_meas_df.plot()

Out[97]:


<matplotlib.axes._subplots.AxesSubplot at 0x7f847413d908>

1.7. Processing Raw Events

For PM event queries one can perform several operations on source, timestamp dataframe.

Event queryEvent processing
{DB}.{DURATION}.{QUERY_PARAMETERS}.{QUERY}
{DB}.{DURATION}.{CIRCUIT_TYPE}.{METADATA}.{QUERY}
.filter_source()
.drop_duplicate_source()
.sort_values()

The processing methods are dedicated to performing repeated operations on PM events. In case of searching a given system and className with wildcard ‘*’ as a source, the event query can return events from different sectors. In this case, one can filter events to contain to a given sector. Some PM systems return duplicate events from different types of boards. In this case one can drop duplicate sources. Eventually, the events can be sorted by either source or timestamp.

  • Filter source

In [98]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QH', source='*') \
    .event_query() \
    .df

source_timestamp_df

Out[98]:

sourcetimestamp
0B20L51426220469491000000
1C20L51426220517100000000
2A20L51426220518112000000
3A21L51426220625990000000
4B21L51426220866112000000
5C23L41426236802332000000
6B23L41426236839404000000
7A23L41426236839832000000
8C22L41426236949841000000
9C15R41426251285711000000
10B15R41426251337747000000
11A15R41426251388741000000
12B34L81426258716281000000
13C34L81426258747672000000
14A34L81426258747370000000
15C33L81426258835955000000
16C34R71426258853947000000
17A34R71426258854113000000
18A20R31426267931956000000
19B20R31426267983579000000
20C20R31426268004144000000
21B18L51426277626360000000
22A18L51426277679838000000
23C18L51426277680496000000
24A19L51426277903449000000

Executing filter_source() with circuit name and system type would filter out events not belonging to a given circuit name

In [99]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QH', source='*') \
    .event_query() \
    .filter_source('RB.A45', 'QH') \
    .df

source_timestamp_df

Out[99]:

sourcetimestamp
0B20L51426220469491000000
1C20L51426220517100000000
2A20L51426220518112000000
3A21L51426220625990000000
4B21L51426220866112000000
5C15R41426251285711000000
6B15R41426251337747000000
7A15R41426251388741000000
8B18L51426277626360000000
9A18L51426277679838000000
10C18L51426277680496000000
11A19L51426277903449000000
  • Drop duplicates

In [100]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QDS', source='*') \
    .event_query() \
    .df

source_timestamp_df

Out[100]:

sourcetimestamp
0B20L51426220469490000000
1C20L51426220517099000000
2A20L51426220518111000000
3A21L51426220625989000000
4B21L51426220866111000000
5B20L51426220469492000000
6C20L51426220517101000000
7A20L51426220518113000000
8A21L51426220625991000000
9B21L51426220866113000000
10C23L41426236802331000000
11B23L41426236839403000000
12A23L41426236839831000000
13C22L41426236949840000000
14C23L41426236802333000000
15B23L41426236839405000000
16A23L41426236839833000000
17C22L41426236949842000000
18C15R41426251285710000000
19B15R41426251337746000000
20A15R41426251388740000000
21C15R41426251285712000000
22B15R41426251337748000000
23A15R41426251388742000000
24B34L81426258716280000000
25C34L81426258747671000000
26A34L81426258747369000000
27C33L81426258835954000000
28C34R71426258853946000000
29A34R71426258854112000000
30B34L81426258716282000000
31C34L81426258747673000000
32A34L81426258747371000000
33C33L81426258835956000000
34C34R71426258853948000000
35A34R71426258854114000000
36A20R31426267931955000000
37B20R31426267983578000000
38C20R31426268004143000000
39A20R31426267931957000000
40B20R31426267983580000000
41C20R31426268004145000000
42B18L51426277626359000000
43A18L51426277679837000000
44C18L51426277680495000000
45A19L51426277903448000000
46B18L51426277626361000000
47A18L51426277679839000000
48C18L51426277680497000000
49A19L51426277903450000000

Executing filter_source() with circuit name and system type would filter out events not belonging to a given circuit name

In [101]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QDS', source='*') \
    .event_query() \
    .filter_source('RB.A45', 'QDS') \
    .df

source_timestamp_df

Out[101]:

sourcetimestamp
0B20L51426220469490000000
1C20L51426220517099000000
2A20L51426220518111000000
3A21L51426220625989000000
4B21L51426220866111000000
5B20L51426220469492000000
6C20L51426220517101000000
7A20L51426220518113000000
8A21L51426220625991000000
9B21L51426220866113000000
10C15R41426251285710000000
11B15R41426251337746000000
12A15R41426251388740000000
13C15R41426251285712000000
14B15R41426251337748000000
15A15R41426251388742000000
16B18L51426277626359000000
17A18L51426277679837000000
18C18L51426277680495000000
19A19L51426277903448000000
20B18L51426277626361000000
21A18L51426277679839000000
22C18L51426277680497000000
23A19L51426277903450000000
  • drop_duplicate_source()

Some PM systems return duplicate events from different types of boards. In this case one can drop duplicate sources.

In [102]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QDS', source='*') \
    .event_query() \
    .filter_source('RB.A45', 'QDS') \
    .drop_duplicate_source() \
    .df

source_timestamp_df

Out[102]:

sourcetimestamp
0B20L51426220469490000000
1C20L51426220517099000000
2A20L51426220518111000000
3A21L51426220625989000000
4B21L51426220866111000000
5C15R41426251285710000000
6B15R41426251337746000000
7A15R41426251388740000000
8B18L51426277626359000000
9A18L51426277679837000000
10C18L51426277680495000000
11A19L51426277903448000000
  • sort_values()

The events can be sorted by either source or timestamp.

In [103]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder

source_timestamp_df = QueryBuilder().with_pm() \
    .with_duration(t_start='2015-03-13 05:20:59.4910002', duration=[(24*60*60, 's')]) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A45', system='QDS', source='*') \
    .event_query() \
    .filter_source('RB.A45', 'QDS') \
    .drop_duplicate_source() \
    .sort_values(by='timestamp') \
    .df

source_timestamp_df

Out[103]:

sourcetimestamp
0B20L51426220469490000000
1C20L51426220517099000000
2A20L51426220518111000000
3A21L51426220625989000000
4B21L51426220866111000000
5C15R41426251285710000000
6B15R41426251337746000000
7A15R41426251388740000000
8B18L51426277626359000000
9A18L51426277679837000000
10C18L51426277680495000000
11A19L51426277903448000000

2. AssertionBuilder()

{SIGNALS}.(TIME_RANGE).{ASSERTION}

Signal inputTime range definition (optional) / Signal assertionSignal assertions (if time range defined)
.with_signal()
.has_min_max_value()
.compare_to_reference()
.with_time_range().has_min_max_variation()
.with_time_range().has_min_max_slope()
  • has_min_max_value()

In [104]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
from lhcsmapi.pyedsl.AssertionBuilder import AssertionBuilder

tt891a_dfs = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start='2014-12-13 09:12:41+01:00', t_end='2014-12-13 12:27:11+01:00') \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system=['LEADS_EVEN', 'LEADS_ODD'], signal='TT891A') \
    .signal_query() \
    .synchronize_time() \
    .convert_index_to_sec() \
    .filter_median().dfs


AssertionBuilder().with_signal(tt891a_dfs) \
    .has_min_max_value(value_min=46, value_max=54)

Out[104]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f8474826c18>

In the case below, the assertion should fail and raise a warning.

In [105]:


AssertionBuilder().with_signal(tt891a_dfs) \
    .has_min_max_value(value_min=50, value_max=54)


/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:114: UserWarning: DACA05_07L2_TT891A.TEMPERATURECALC outside of the [50, 54] mV threshold
  warnings.warn('{} outside of the [{}, {}] mV threshold'.format(col, value_min, value_max))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:114: UserWarning: DACA06_07L2_TT891A.TEMPERATURECALC outside of the [50, 54] mV threshold
  warnings.warn('{} outside of the [{}, {}] mV threshold'.format(col, value_min, value_max))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:114: UserWarning: DABA01_07R1_TT891A.TEMPERATURECALC outside of the [50, 54] mV threshold
  warnings.warn('{} outside of the [{}, {}] mV threshold'.format(col, value_min, value_max))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:114: UserWarning: DABA02_07R1_TT891A.TEMPERATURECALC outside of the [50, 54] mV threshold
  warnings.warn('{} outside of the [{}, {}] mV threshold'.format(col, value_min, value_max))

Out[105]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f84748a6c88>
  • compare_to_reference()

In [106]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
from lhcsmapi.pyedsl.AssertionBuilder import AssertionBuilder
from lhcsmapi.reference.Reference import Reference
from lhcsmapi.Time import Time

timestamp_ee_rqd = 1544622149701000000
timestamp_fgc_rqd = 1544622149620000000
signal_names = 'T_RES'


t_res_df = QueryBuilder().with_pm() \
    .with_timestamp(timestamp_ee_rqd) \
    .with_circuit_type('RQ') \
    .with_metadata(circuit_name='RQD.A12', system='EE', signal=signal_names).signal_query() \
    .remove_values_for_time_less_than(timestamp_ee_rqd) \
    .synchronize_time(timestamp_fgc_rqd) \
    .convert_index_to_sec().dfs[0]


timestamp_ee_ref_rqd = Reference.get_power_converter_reference_fpa('RQ', 'RQD.A12', 'eePm')
timestamp_ee_ref_rqd = Time.to_unix_timestamp(timestamp_ee_ref_rqd)

timestamp_fgc_ref_rqd = Reference.get_power_converter_reference_fpa('RQ', 'RQD.A12', 'fgcPm')
timestamp_fgc_ref_rqd = Time.to_unix_timestamp(timestamp_fgc_ref_rqd)


t_res_ref_df = QueryBuilder().with_pm() \
    .with_timestamp(timestamp_ee_ref_rqd) \
    .with_circuit_type('RQ') \
    .with_metadata(circuit_name='RQD.A12', system='EE', signal=signal_names).signal_query() \
    .remove_values_for_time_less_than(timestamp_ee_ref_rqd) \
    .synchronize_time(timestamp_fgc_ref_rqd) \
    .convert_index_to_sec().dfs[0]

AssertionBuilder().with_signal([t_res_df])\
    .compare_to_reference(signal_ref_dfs=[t_res_ref_df], abs_margin=25, scaling=1)

Out[106]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f8474314828>
  • has_min_max_variation()

In [111]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
from lhcsmapi.pyedsl.AssertionBuilder import AssertionBuilder
from lhcsmapi.analysis.CircuitAnalysis import get_current_plateau_start_end

t_start = '2014-12-13 09:12:41+01:00'
t_end = '2014-12-13 12:27:11+01:00'

cv891_dfs = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start, t_end=t_end) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system=['LEADS_EVEN', 'LEADS_ODD'], signal='CV891') \
    .signal_query() \
    .synchronize_time() \
    .convert_index_to_sec() \
    .filter_median() \
    .dfs

i_meas_raw_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start, t_end=t_end) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='PC', signal='I_MEAS') \
    .signal_query() \
    .dfs[0]

plateau_timing_df = get_current_plateau_start_end(i_meas_raw_df, i_meas_threshold=500)

AssertionBuilder().with_signal(cv891_dfs) \
    .with_time_range(t_start=plateau_timing_df['plateau_start_sync'], t_end=plateau_timing_df['plateau_end_sync']) \
    .has_min_max_variation(variation_min_max=8)

Out[111]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f846fd924a8>

In the case below, the variation is too tight and the assertion fails

In [112]:


AssertionBuilder().with_signal(cv891_dfs) \
    .with_time_range(t_start=plateau_timing_df['plateau_start_sync'], t_end=plateau_timing_df['plateau_end_sync']) \
    .has_min_max_variation(variation_min_max=1)


/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DACA05_07L2_CV891.POSST (1.0 %) exceeds 1.5 % for constant current from 806.0 to 5882.5 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DACA06_07L2_CV891.POSST (1.0 %) exceeds 1.9000000000000021 % for constant current from 806.0 to 5882.5 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DABA01_07R1_CV891.POSST (1.0 %) exceeds 1.6999999999999993 % for constant current from 806.0 to 5882.5 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DABA01_07R1_CV891.POSST (1.0 %) exceeds 1.1000000000000014 % for constant current from 6199.0 to 9745.0 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DABA02_07R1_CV891.POSST (1.0 %) exceeds 2.099999999999998 % for constant current from 806.0 to 5882.5 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:219: UserWarning: The variation of DABA02_07R1_CV891.POSST (1.0 %) exceeds 1.2000000000000028 % for constant current from 6199.0 to 9745.0 s
  .format(col, variation_min_max, variation.values[0], t_s, t_e))

Out[112]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f84742bbdd8>
  • has_min_max_slope()

In [114]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
from lhcsmapi.pyedsl.AssertionBuilder import AssertionBuilder
from lhcsmapi.analysis.CircuitAnalysis import get_current_plateau_start_end

t_start = '2014-12-13 09:12:41+01:00'
t_end = '2014-12-13 12:27:11+01:00'

u_res_dfs = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start, t_end=t_end) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system=['LEADS_EVEN', 'LEADS_ODD'], signal='U_RES') \
    .signal_query() \
    .synchronize_time() \
    .convert_index_to_sec() \
    .filter_median() \
    .dfs

i_meas_raw_df = QueryBuilder().with_nxcals(spark) \
    .with_duration(t_start=t_start, t_end=t_end) \
    .with_circuit_type('RB') \
    .with_metadata(circuit_name='RB.A12', system='PC', signal='I_MEAS') \
    .signal_query() \
    .dfs[0]

plateau_timing_df = get_current_plateau_start_end(i_meas_raw_df, i_meas_threshold=500)

AssertionBuilder().with_signal(u_res_dfs) \
    .with_time_range(t_start=plateau_timing_df['plateau_start_sync'], t_end=plateau_timing_df['plateau_end_sync']) \
    .has_min_max_slope(slope_min=-2, slope_max=2)

Out[114]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f84745c6668>

In the case below, the slope is too tight and the assertion fails

In [116]:


AssertionBuilder().with_signal(u_res_dfs) \
    .with_time_range(t_start=plateau_timing_df['plateau_start_sync'], t_end=plateau_timing_df['plateau_end_sync']) \
    .has_min_max_slope(slope_min=-2e-3, slope_max=2e-3)


/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7L2.RB.A12.LD1:U_RES is -0.119 mV/h for constant current from 806.0 to 5882.5 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7L2.RB.A12.LD1:U_RES is -0.667 mV/h for constant current from 6199.0 to 9745.0 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7L2.RB.A12.LD2:U_RES is 0.159 mV/h for constant current from 806.0 to 5882.5 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7L2.RB.A12.LD2:U_RES is 0.636 mV/h for constant current from 6199.0 to 9745.0 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7R1.RB.A12.LD3:U_RES is 0.205 mV/h for constant current from 806.0 to 5882.5 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7R1.RB.A12.LD3:U_RES is 0.421 mV/h for constant current from 6199.0 to 9745.0 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7R1.RB.A12.LD4:U_RES is -0.188 mV/h for constant current from 806.0 to 5882.5 s
  .format(col, slope, unit, t_s, t_e))
/eos/home-m/mmacieje/SWAN_projects/lhc-sm-api/lhcsmapi/pyedsl/AssertionBuilder.py:240: UserWarning: The drift of DFLAS.7R1.RB.A12.LD4:U_RES is -0.469 mV/h for constant current from 6199.0 to 9745.0 s
  .format(col, slope, unit, t_s, t_e))

Out[116]:


<lhcsmapi.pyedsl.AssertionBuilder.AssertionBuilderSignalPlot at 0x7f846fd65400>

3. FeatureBuilder()

{SIGNALS}.(FEATURE_CALCULATION).{ASSERTION}

e.g.


FeatureBuilder().with_signal(u_hds_dfs) \
                .calculate_features(features=['first', 'last20mean', 'tau_charge'], index=1544622149599000000)

Supported functions are:


['first', 'first20mean', 'last', 'last20mean', 'max', 'min', 'median', 'std', 'mean', 'tau_charge', 'tau_energy', 'tau_lin_reg', 'tau_exp_fit']

BROKEN IMAGE NOT MOVED (drupal url : https://sigmon.web.cern.ch/node/28)

For example, to calculate initial voltage, final mean voltage based on the last 20 points, and the characteristic time of the pseudo-exponential decay for a quench heater voltage.

In [117]:


from lhcsmapi.pyedsl.QueryBuilder import QueryBuilder
from lhcsmapi.pyedsl.FeatureBuilder import FeatureBuilder
import matplotlib.pyplot as plt

timestamp = 1544622149599000000

u_hds_dfs = QueryBuilder().with_pm() \
    .with_timestamp(timestamp) \
    .with_circuit_type('RQ') \
    .with_metadata(circuit_name='RQD.A12', system='QH', signal='U_HDS', source='16L2', wildcard={'CELL': '16L2'}) \
    .signal_query()\
    .synchronize_time(timestamp)\
    .convert_index_to_sec().dfs

ax = u_hds_dfs[0].plot(figsize=(15,7))
u_hds_dfs[1].plot(ax=ax, grid=True)
plt.show()

FeatureBuilder().with_signal(u_hds_dfs) \
                .calculate_features(features=['first', 'last20mean', 'tau_charge'], index=1544622149599000000)

Out[117]:

16L2:U_HDS_1:first16L2:U_HDS_1:last20mean16L2:U_HDS_1:tau_charge16L2:U_HDS_2:first16L2:U_HDS_2:last20mean16L2:U_HDS_2:tau_charge
1544622149599000000880.46215.5750860.07779872.83546.7347030.076704
